Technicial Specifications

Product Code XEROX VERSANT 4100

Product Group Digital Presses

Printing Technology Laser

Color Capability Colour

Print Quality Laser

Double Sided Printing Auto

Fax N/A

Copy N/A

Scan N/A

Smart Printer Available

Feeding Type Manual, Automatic, Flatbed, Tray

Connection Type USB, Ethernet, Wi-Fi, Mobile

Compatible Softwares Print Management, WorkFlow Software, ConnectKey, Xerox Mobility, LPM - Lidya Print Management

Rated speed 100 PPM (8.5" x 11"/A4 letter), 52-300 gsm 80 PPM (8.5" x 11"/A4 letter), 301-400 gsm 52 PPM (11" x 17"/12" x 18"/A3), 52-300 gsm 44 PPM (11" x 17"/A3), 301-400 gsm

Resolution 2400 x 2400 dpi VCSEL ROS for sharpness, detailed shadows, and bright highlights 1200 x 1200 x 10 RIP rendering without down sampling for Ultra HD performance

Recommended average monthly volume 250,000 pages per month

Duty cycle 1,200,000 pages per month

Line Screens Halftone Screens for smoother, crisper resolution and improved gradients 150, 175, 200, 210, 300, 600 Clustered Dot 150, 200, 300 Rotated Line Screen FM Stochastic Screen

Standard Capabilities Color printing

Optional Capabilities High-capacity feeding, stacking, and finishing

Printed Sides Duplex

MICR No

Color Technology Automated Color Quality Suite via Full Width Array

Paper sources 3 standard, 2 high capacity and 1 optional manual sheet inserter

Standard paper capacity 3,900 sheets

Maximum paper capacity with options 9,900 sheets

Media Dimensions - Minimum 3.9" x 5.7" (98 mm x 146 mm)

Media Dimensions - Maximum Maximum extra long size: 13 x 47.2" (330 mm x 1.2 m) / Maximum standard size: 13 x 19.2" (330 x 488 mm)

Media Weight - Minimum 52 gsm

Media Weight - Maximum 400 gsm

Media Types Coated and uncoated papers, bright papers, labels, business cards, glossy brochures, window decals, durable/synthetic papers, greeting cards, tabs, embossed, polyesters and custom solutions Mixed-stock jobs supported

Auto Duplex High Capacity trays (52 - 400 gsm) Standard trays (52 - 256 gsm) Manual sheet inserter (52 - 400 gsm)

Tray 1 550 sheets

Tray 2 550 sheets

Tray 3 550 sheets

Optional High Capacity Feeder High Capacity Feeder: One Tray 2,000 sheets, 8.5" x 11"/A4, 64 - 220 gsm — uncoated only Oversized High Capacity Feeder: One Tray 2,000* sheet capacity, min size with Tray Inserter 3.9" x 5.8" (100 x 148 mm), max size 13" x 19.2" (330 x 488 mm); 52 gsm up to 400 gsm — uncoated and coated Advanced Oversized High Capacity Feeder: Two Trays 4,000* sheet capacity, min size with Tray Inserter 3.9"x 5.8" (98 x 148 mm), max size 13" x 19.2" (330 x 488 mm); 52 gsm up to 400 gsm — uncoated and coated Dual Advanced Oversized High Capacity Feeder: Four Trays 8,000* sheet capacity, min size with Tray Inserter 3.9"x 5.8" (98 x 148 mm), max size 13" x 19.2" (330 x 488 mm); 52 gsm - 400 gsm — uncoated and coated High Capacity XLS Vacuum Feeder: Two Trays 2,800* sheets capacity, min size with Tray Inserter 3.9"x 5.8" (98 x 148 mm), standard max size 13" x 19.2" (330 x 488 mm); top tray for XLS up to 13 x 47.2" (330 mm x 1.2 m); 52 gsm up to 400 gsm — uncoated and coated Dual High Capacity XLS Vacuum Feeder: Four Trays 7,000* sheets capacity, min size with Tray Inserter 3.9"x 5.8" (98 x 148 mm), standard max size 13" x 19.2" (330 x 488 mm); top tray for XLS up 13 x 47.2" (330 mm x 1.2 m); 52 gsm up to 400 gsm — uncoated and coated * Manual Sheet Inserter Tray included with feeder up to 250 sheet capacity: max size 13" x 26" (330 x 660 mm)

Inserter 250-sheet Xerox Inserter

Digital Front Ends Xerox® EX-P 4100 Print Server Powered by Fiery® Xerox® EX 4100 Print Server Powered by Fiery®

Electrical Requirements Base Configuration: 208-240 VAC, 50/60 Hz, 30A (sole use)/single phase/NEMA 14-30 Additional electrical required for print server, feeding/finishing devices 115 VAC 15 Amp for 60 Hz or 220 VAC 10 Amp for 50 Hz (Western Hemisphere) 220-240 Volts, 10 Amp, 50 Hz (Europe)

Dimensions Height: 44" (1,110 mm) Width: 105" (2,670 mm) Depth: 32" (807 mm)

Sustainability EPEAT ENERGY STAR®
