Technicial Specifications

Product Code XEROX VERSANT 280

Product Group Digital Presses

Printing Technology Laser

Color Capability Colour

Print Quality Laser

Double Sided Printing Auto

Fax N/A

Copy Available

Scan Available

Smart Printer Available

Feeding Type Manual, Automatic, Flatbed, Tray

Connection Type USB, Ethernet, Wi-Fi, Mobile

Compatible Softwares Print Management, WorkFlow Software, ConnectKey, Xerox Mobility, LPM - Lidya Print Management

Rated speed 80 ppm (8.5" x 11"/A4), 52-400 gsm with ASRS & Performance Package 80 ppm (8.5" x 11"/A4), 52-220 gsm 60 ppm (8.5" x 11"/A4), 221-400 gsm 44 ppm (11" x 17"/A3), 52-400 gsm with ASRS & Performance Package 44 ppm (11" x 17"/A3), 52-220 gsm 32 ppm (11" x 17"/A3), 221-400 gsm

Resolution 2400 x 2400 dpi VCSEL ROS for sharpness, detailed shadows, and bright highlights 1200 x 1200 x 10 RIP rendering without down sampling for Ultra HD performance

Recommended average monthly volume 80,000 pages per month

Duty cycle 750,000 pages per month

Line Screens Halftone Screens for smoother, crisper resolution and improved gradients 150, 175, 200, 300, 600 Clustered Dot 150, 200 Rotated Line Screen FM Stochastic Screen

Configurations Xerox® Versant® 280 Press Xerox® Versant® 280 Press with All Stocks Rated Speed (ASRS) option Xerox® Versant® 280 Press with Performance Package (PP) option

Standard Capabilities Color printing, copying, and scanning

Optional Capabilities Feeding, Finishing, Workflow, Performance options

Printed Sides Duplex

MICR No

Other Scanning Features E-Mail: Scan documents to email addresses as attachments to the emails Network Scanning: Scan documents to the print server for further routing Scan to PC: Scan documents to a Windows® PC Store to USB: Scan documents to a flash drive plugged into the USB port Store to Folder: Scan documents to a folder on the press for storage

Color Technology Automated Color Quality Suite

Paper sources 3 standard trays plus bypass; 6 optional high capacity feeders

Standard paper capacity 1,900 sheets

Maximum paper capacity with options 9,900 sheets

Media Dimensions - Minimum 3.9" x 5.7" (98 mm x 146 mm)

Media Dimensions - Maximum Maximum extra long size: 13 x 47.2" (330 mm x 1.2 m) / Maximum standard size: 13 x 19.2" (330 x 488 mm)

Media Weight - Minimum 52 gsm

Media Weight - Maximum 400 gsm#42; (#42;Xerox Versant 280 Tested Substrate List)

Media Types Coated and uncoated papers, bright papers, labels, business cards, glossy brochures, window decals, durable/synthetic papers, greeting cards, tabs, embossed, polyesters and custom solutions Mixed-stock jobs supported

Auto Duplex High Capacity trays (52 - 350 gsm) Standard trays (52 - 256 gsm) Manual sheet inserter (52 - 350 gsm)

Tray 1 550 sheets

Tray 2 550 sheets

Tray 3 550 sheets

Optional High Capacity Feeder High Capacity Feeder: One Tray 2,000 sheets, 8.5" x 11"/A4, 64 - 220 gsm — uncoated only Oversized High Capacity Feeder: One Tray 2,000* sheet capacity, min size with Tray Inserter 3.9" x 5.8" (100 x 148 mm), max size 13" x 19.2" (330 x 488 mm); 52 gsm up to 400 gsm — uncoated and coated Advanced Oversized High Capacity Feeder: Two Trays 4,000* sheet capacity, min size with Tray Inserter 3.9"x 5.8" (98 x 148 mm), max size 13" x 19.2" (330 x 488 mm); 52 gsm up to 400 gsm — uncoated and coated Dual Advanced Oversized High Capacity Feeder: Four Trays 8,000* sheet capacity, min size with Tray Inserter 3.9"x 5.8" (98 x 148 mm), max size 13" x 19.2" (330 x 488 mm); 52 gsm - 400 gsm — uncoated and coated High Capacity XLS Vacuum Feeder: Two Trays 2,800* sheets capacity, min size with Tray Inserter 3.9"x 5.8" (98 x 148 mm), standard max size 13" x 19.2" (330 x 488 mm); top tray for XLS up to 13 x 47.2" (330 mm x 1.2 m); 52 gsm up to 400 gsm — uncoated and coated Dual High Capacity XLS Vacuum Feeder: Four Trays 7,000* sheets capacity, min size with Tray Inserter 3.9"x 5.8" (98 x 148 mm), standard max size 13" x 19.2" (330 x 488 mm); top tray for XLS up 13 x 47.2" (330 mm x 1.2 m); 52 gsm up to 400 gsm — uncoated and coated * Manual Sheet Inserter Tray included with feeder up to 250 sheet capacity: max size 13" x 26" (330 x 660 mm)

Standard Duplex Automatic Document Feeder Single-pass Duplex Automatic Document Feeder, up to 200 ipm color / B&W, 250-sheet capacity, up to 11" x 17" (A3), 38 gsm (16 lb. bond) to 200 gsm (53 lb. bond), copy or scan to a variety of output options

Inserter 250-sheet Xerox Inserter

Digital Front Ends Xerox® EX 280 Print Server Powered by Fiery® Xerox® EX-i 280 Print Server Powered by Fiery®

Electrical Requirements North America: 208-240 V, 50/60 Hz, 16 amps/requires 20A circuit, NEMA 6-20-R socket Europe: 220-240 V, 50 Hz, 20 amps/requires 20A circuit, PCE Shark 023-6 mating socket Additional electrical required for print server and feeding/finishing devices: 115 VAC, 15 Amp for 60 Hz or 220 VAC, 10 Amp for 50 Hz (Western Hemisphere) 220-240 Volts, 10 Amp, 50 Hz (Europe)

Dimensions 30" (W) x 33" (D) x 48" (H) 760 mm (W) x 831 mm (D) x 1,212 mm (H) Weight: 651 lb. (295 kg)

Sustainability EPEAT ENERGY STAR®
